Yüzer Test Adaptörleri

Electric Vehicles (LEV) including e-bikes, e-scooters and pedelecs as well as for UGVs and drones. Providing fast and reliable magnetic connection, these are particularly suited to data communication and power transmission of voltages up to 60 V and current loads up to 40 A. The magnetic locking and precision self-mating capability prevents any accidental or forced disconnection from damaging the connector or the LEV. Furthermore, the high tolerance pin and socket design permits a large number of mating cycles. The RoPD® connection system is ideal for many LEV connection applications – including battery changing and charging – where frequent connection and disconnection is required. The four data contacts and two power transmission pins make a hot-plug capability unnecessary as the data contacts activate the power following connection. For added flexibility the data contacts can be used as a BUS system with an additional supply voltage. Versions of the RoPD® system are also available for EnergyBus applications.

Rosenberger HFM® is the next generation of coaxial connectors for the automotive industry. For frequencies up to 15 GHz, the intelligent modular system ensures fast transmission of high data rates up to 20 Gbps. Its innovative design addresses the growing requirement for cost savings as well as reduced weight and size. Delivering space savings of up to 80 % compared to conventional FAKRA connectors, the Rosenberger HFM® connector system allows various modules to be accommodated in the smallest possible footprint.

Rosenberger RPC-TNC precision connectors feature threaded locking mechanism and are suitable for applications up to 18 GHz. Based on the BNC series interface, they are intermateable with standard TNC connectors, 50 Ω and 75 Ω types both. The wide product range includes cable connectors, adaptors and test & measurement accessories such as calibration kits or measurement equipment (open – short – load). Furthermore, variants for aviation and spaceflight applications are available.
