1.6-5.6 connectors perform at 75 Ohm up to 4/12 GHz and are characterized by high mechanical and electrical stability. They are mainly used for reliable transmission of high bit-rates.
IInd and IIIrd generation 1.6-5.6 connectors are intermateable and feature different coupling mechanisms for allowing male types to be connected to all female types.
The screw-on coupling version provides positive, familiar mating, while the quick-lock/push-pull coupling version enables quick installation. This series complies with CECC 22240 standards.
Rosenberger provides a wide range of compact calibration kits in various series for MSOT (4-in-1) and MSO (3-in-1) calibrations.
Compact calibration kits combine all necessary calibration standards in one unit and can be applied for MSO calibrations (3-in-1, open, short, load) of single port vector network analyzers and MSOT calibrations (4-in-1, open, short, load, thru) of 2- or more-port vector network analyzers. All compact calibration kits come in a hardshell case with a lanyard and with general coefficients on a standard definition card.
Rosenberger, as a dependable development partner of highly accurate industrial measurement technology, develops and produces a comprehensive range of calibration kits for a variety of standard and precision interfaces for vector network analyzers (VNAs).
RosenbergerHSD® is a homogeneous impedance-controlled interconnect system which directly addresses the high-speed data, low-voltage requirements of real-time automotive industry applications. Extremely compact and durable this 100 Ohm fully shielded interconnect system utilizes shielded twisted quad cables and features mechanical keying and latching for high connection retention, as well as coding to avoid misuse. Furthermore, these precision manufactured RosenbergerHSD®SF variants are ideally suited for process-safe and fully automated assembly by harness makers, facilitating a significant reduction in costs.
Its high data throughput performance while also preventing interference from crosstalk and external sources makes the RosenbergerHSD® cable and PCB connector system the perfect choice for LVDS cameras, USB connections and IEEE 1394 applications. In addition, it is well-suited to many other applications including those found in digital infotainment electronics and digital symmetrical networks – even radio base stations.
