5G Anten Çözümleri

Rosenberger has many years of experience in the manufacture of high quality cable assemblies for a wide variety of industrial test & measurement applications. Our standard microwave cable assemblies for vector network analyzers (VNA), for example, are characterized by their excellent electrical and mechanical performance for frequencies up to 110 GHz. The range includes ultra-low loss cables for antennas or applications with high power requirements; miniature cables for test systems or applications demanding high flexibility; indoor and outdoor cables; specially shielded cables and extremely phase stable cables for test & measurement applications. In defined lengths armoured RFlex™ cables are also available. Customer-specific assemblies and solutions can be ordered on request.

Rosenberger HFM® is the next generation of coaxial connectors for the automotive industry. For frequencies up to 15 GHz, the intelligent modular system ensures fast transmission of high data rates up to 20 Gbps. Its innovative design addresses the growing requirement for cost savings as well as reduced weight and size. Delivering space savings of up to 80 % compared to conventional FAKRA connectors, the Rosenberger HFM® connector system allows various modules to be accommodated in the smallest possible footprint.

Rosenberger’s new RPC-1.35* precision connector series meets the growing demand for precision, high-performance RF-connections up to 90 GHz. The range addresses the expanding market for 5G, industrial sensors in the E-Band, millimeter wave sensors for self-driving vehicles, WLAN IEEE 802.11ax and 802.11ay. RPC-1.35 connectors offer a highly robust mechanical design, minimum 3000 mating cycles, high connector repeatability, and maximum return loss values – ideal for ensuring RF measurements in the E-Band without delays. The product portfolio covers semi-rigid and flexible cable assemblies, PCB connectors, test PCBs, cable connectors, in-series and inter-series adaptors, test ports, floating and waveguide-to-coaxial adaptors as well as gauge and calibration kits. *A working group, comprising PTB (Physikalisch Technische Bundesanstalt), Rosenberger, Rohde & Schwarz and Spinner, designed the new 1.35 mm connector to close the gap between 1.85 mm and 1.00 mm connectors. The interface standardization is in progress.

Rosenberger QN coaxial connectors are based on the N connector interface. With a frequency range of up to 11 GHz depending on the connector and cable type, the quick-lock mechanism enables reliable and easy connection, 10 times faster than standard N offerings. Ideal for tight spaces such as those found in mobile base stations, the packing density of QN exceeds that of N connectors due to the minimum pitch and toolless assembly. Torque spanners are not required. QN and standard N connectors are not intermateable.
