Yüksek Katlı Bina Çözümleri

The Rosenberger portable and multifunctional broadband PIM Site Analyzer alpha provides the best alternative of performing the most precise and efficient PIM tests on site. The PIM Site Analyzer alpha consists of a single master unit with band-specific, interchangeable filter units, since the form factor of the filter units is the same. Take out one filter unit, e.g., 900 MHz, and replace with another filter unit, e.g., 1800 MHz, without any calibration of the filter unit, potential adaptors, test cable, or operational mode(s). Future-proof plug and play concept covering 700 to 2700 MHz.

The cable construction is similar for all cable sizes: Inner conductor, foam dielectric, outer conductor and outer jacket. The cables are available as standard with either a PE jacket for outdoor installations or in a flame retardant and halogen-free version to comply with indoor requirements for health and safety, IEC 60332 and CPR-EN 50575.

Rosenberger FAKRA* industry standard compatible connectors are designed to fulfill the rigorous mechanical and environmental requirements of the automotive industry. Ensuring maximum electrical and mechanical performance, these high quality FAKRA connectors feature specific color coded plastic housings in accordance with the FAKRA coding industry standard. Thirteen distinct mechanical and color codes enable easy identification and unique keying to avoid mis-mating and additional one neutral coding. Combining Rosenberger’s turned part production expertise and FAKRA SF stamped and formed technology these precision manufactured products are ideally suited for process-safe and fully automated assembly by harness makers – leading to a significant reduction in production costs. Rosenberger FAKRA products are compliant to ISO 20860-1 & 2 and USCAR 18 standards.

Rosenberger SLC (Spring Loaded Contacts) are suited to customized designs and frequencies up to 6 GHz. The product portfolio ensures impedance controlled SLC for transmission of RF signals across a diverse range of customized products and applications, such as backplane designs and those requiring a high degree of tolerance compensation between mating partners. Rosenberger SLC connectors and assemblies are therefore a perfect fit for specialized board-to-board applications, hybrid SLC solutions – with a combination of DC, RF signal transmission, power supply and fiber optical lines – as well as SLC cable connectors, board and panel mounted products.
