HVR®300

The Rosenberger FTTA/PTTA Connectivity Boxes are available in standard and tailor-made designs and configurations, in low or high volumes, to meet OEM or Network Operator requirements as to efficient, reliable and easy-to-deploy connectivity boxes. Rosenberger connectivity boxes, designed and produced in-house at Rosenberger in Germany, provide the best workmanship and highest quality to ensure a long and smooth operation even in the most harsh environments.

Complementing its standard HV connector portfolio, Rosenberger develops and manufactures customer-specific high-voltage components for electric and hybrid vehicles. These enable the lowest possible transition resistances, ensuring long-term low-loss performance and reliability in critical electrical systems such as those for battery charging, cell management, heating, and air conditioning. From concept to final delivery, Rosenberger high voltage custom components are the perfect fit every time. Using its component toolkit, including PDUs, Y-splitters, Busbars and Cell Modules, Rosenberger can develop and manufacture a wide array of tailor-made solutions. These are designed and configured precisely to the relevant vehicle architecture, allowing ideal combinations of the various fuses, relays and other passive and active components required. Power Distribution Units (PDU) Power distribution units (PDU) for vehicles have multiple power input and outputs and use all kinds of connectors, fuses, and relays. In these cases, the PDU generally forms the central link between the vehicle power electronics and batteries, electric motors, and other ancillary units. Y-Splitters Y-splitters are used to distribute the power from one cable harness to two or more units, e.g., between a DC/DC converter and an electric air-conditioning unit. Rosenberger can design Y-splitters for applications with and without shielding for cable cross sections from 4 mm² to 95 mm² in collaboration with the customer. Cell Module Connectors The Rosenberger HV portfolio also includes cell module connectors. These connectors are required to link battery modules within a battery pack. For typical battery applications, multiple custom-designed battery connection points are required. Based on the robust pressure contact system, Rosenberger offers cell module connectors without flexing parts in the contact area. Systems from 100 to 350 A are available. Different assembly directions, coding variants as well as cross sections can be implemented according to customer-specific requirements.

Rosenberger MCX 50 Ω coaxial connectors feature a snap-on locking mechanism. They are mainly applied in RF cable connections up to 6 GHz such as those found in fixed and wireless communication systems. MCX connectors offer high reliability, long service life, as well as easy and fast mounting. The PCB connectors are supplied in tape and reel packaging for automatic assembly to boards and in blisters. MCX connectors with 75 Ω characteristic impedance are available on request.
