Fusion-spliced, field-terminated connector for FTTH FuseConnect ™

The RS03 is designed and developed with emphasis on operability and usability where less force is required for the stripping process. Furthermore,equipped with new features such as large capacity battery for 600 stripping cycles, 6 times larger than conventional stripper, and wireless link with smartphones for operational parameters adjustment. These fiber stripping tools are also compatible with stripping Fujikura latest Spider Web RibbonTM ,which consists of optical fibers (with a coating diameter of 250μm or 200 μm) fixed intermittently.

The TJ series are designed for temporary jointing of optical fiber andor ribbon by using fiber holder.

ADC-13/18/19 supplies DC poer exclusively for Fujikura Fusion Splicers.ADC series can be used as an AC adapter, battery charger or an external DC poer inlet port.

The 90R16 is a mass fusion splicer capable of splicing up to 16 fiber ribbon cables simultaneously. In previous mass fusion splicer models, the v-grooves could become dirty over time due to debris and glass deposits from splicing accumulating in the v-grooves. Which in turn, could lead to fibre offsets and high losses if they were not regularly cleaned which added to the overall process time. The 90R16 comes with a first of its kind, innovative user replaceable V-groove assembly which makes this issue a thing of the past and is supplied as standard equipment with the 90R16 kit. This new V-groove assembly can be quickly and easily fitted in the field, minimizing downtime and maximising productivity. In addition, the new V-groove design enables splicing of both conventional type 12-fiber encapsulated ribbon and SWR (Spider Web Ribbon) whilst also accommodating 250um and 200um pitch fibers. The 90R16 can also splice single fibers if required. also making use of Active Blade Management Technology, which now can connect to two CT50 cleavers simultaneously. Features
